Model

4i

Channels

1408

Signal Tracking

GPS : L1C/A, L1C, L2C, L2P, L5

BDS : B1I , B2I , B3I , B1C, B2a, B2b

GLONASS : G1, G2, G3

Galileo : E1, E5a, E5b, E6

QZSS: L1C/A, L1C, L2C, L5

SBAS: L1

NAVIC: L5

High Precision Static

H：±（2.5+0.5×10 D）mm
V：±（5+0.5×10 D）mm

RTK

H：±（8+1×10 D）mm
V：±（15+1×10 D）mm

Tilt Compensation

Accuracy

±（8+0.3TILT）mm

Angle

0~120°

Update Rate

100Hz

System Parameters

Operating System

RTOS

Data Record

DAT

Bluetooth

BT5.0 Backward compatibility

Radio

Power

1w

Frequency

410 – 470MHz

Global
Communication
Protocol

TRIMTALK 450S 、TRIMMARKⅢ 、SOUTH9600、
SOUTH19200、SATEL9600、SATEL19200、
TRANS PARENT

Operation Mode

Transceiver

Power

Voltage

5-12V Power Delivery

Working Time

18h ( Network Mode ) , 15h ( Radio Reception ) , 8h( Radio Transmission )

Port Indicator

SMA

Connecting the radio antenna

Type-C

For charging & Data connection

Indicatore Lights

satellite, datalink, bluetooth, battery light

Physical

Dimension

98mm*53mm(Excluding 5/8 pin interface)

Weight

380g

Environmental

Operating
Temperature

-30℃ 〜 +70℃

Storage Temperature

-40℃ 〜 +80℃

Water/Dust Proof

IP67

Shock

Normal temperature resistance of 1.5 m drop (hard ground)

Humidity

Up to 100%
