GPS RTK STEC SV1 Grey Stake Out Solutions

STEC

GPS GNSS Geodetik RTK Satelit SV1 STEC Satelit Technology– 1,408 channels
-Support GPS, GLONASS, BDS, BEIDOU, GALILEO, SBAS, QZSS, L-band
-Frekuensi 410-470 Mhz
-2 Sensors mega CMOS imaging sensors
-Data Tranfer Type-C USB Transfer Supports FTP/HTTP download
-Static H: 2.5mm±0.5ppm (RMS) V: 5mm±0.5ppm (RMS)
-Real-time Kinematic H: 8mm±1ppm (RMS) V: 15mm±1ppm (RMS)
-Battery Capacity 6800 mAh.
-Unit ringan dengan berat 740gram
-Penyimpanan 8gb SSD
-Waterproof & Dustproof IP68GPS RTK SATELIT SV1 include

Free Pelatihan dan Demo WA : 081 323 67 3998 (Bpk Wova)
PAKET PEMBELIAN GPS GNSS Geodetik RTK Satelit SV1 STEC Satelit Technology :
● 1x Base
● 1x Rover
● 1x Controller Android
● 1x Tripod Statif
● 1x Stik/Pole/Jalon
● 1x TribrachSpesifikasi GPS RTK STEC SV1 :

SATELLITE PERFORMANCE
Channels 1,408
GPS L1C/A, L2C, L2P(Y), L5
GLONASS L1, L2
BEIDOU B1l, B2l, B3l, B1C, B2a, B2b
GALILEO E1, E5a, E5b, E6
QZSS L1, L2, L5, L6
SBAS L1, L5
L-Band B2b PPP
Positioning Rate 1-20Hz
ACCURACY
Code Differential H: 0.40m (RMS)
V: 0.80m (RMS)
Static H: 2.5mm±0.5ppm (RMS)
V: 5mm±0.5ppm (RMS)
Real-time Kinematic H: 8mm±1ppm (RMS)
V: 15mm±1ppm (RMS)
Network PPK H: 3mm±1ppm (RMS)
V: 5mm±1ppm (RMS)
IMU MEASUREMENT
Tilt Angle Maximum 60°
Accuracy 2cm
DATA STORAGE
Type & Storage SSD 8GB
External USB Pen drive
Data Tranfer Type-C USB Transfer
Supports FTP/HTTP download
Differential Format RTCM 2.1, RTCM 2.3, RTCM 3.0,
RTCM 3.1, RTCM 3.2, NMEA 0183,
PJK plane coord., binary code,
Trimble GSOF
GPS Output Format VRS, FKP, MAC
Network Model Ntrip fully supportable
CAMERA
Optical Format 1/5 inch
Pixel Size 1.75*1.75μm
Active Pixel Array 1616*1232
Sensor 2 mega CMOS imaging sensors
COMMUNICATION
I/O Type-C (OTG+Fast Charge+Ethernet)
Antenna Port All-in-one port for radio/GPRS antenna
Network Modem Nano-SIM card
LTE FDD, LTE TDD, UMTS, GSM
UHF Radio 2W Tx/Rx
410-470MHz
Protocol S-LINK, TrimTalk, Hi-target, SOUTH,

Rp95.000.000 Rp125.000.000

Gunakan fitur ini untuk chatting dengan admin kami.

Wova S. Nirwana Bantuan Online Need Help? Chat us via Whatsapp WA : 6281323673998 Chat
Rendy Adiwijaya Sales Agen Online Need Help? Chat us via Whatsapp WA : 6282128000498 Chat

GPS RTK STEC SV1 Grey Stake Out Solutions GNSS RECEIVER

Spesifikasi SV1 :

– 1,408 channels
-Support GPS, GLONASS, BDS, BEIDOU, GALILEO, SBAS, QZSS, L-band
-Frekuensi 410-470 Mhz
-2 Sensors mega CMOS imaging sensors
-Data Tranfer Type-C USB Transfer Supports FTP/HTTP download
-Static H: 2.5mm±0.5ppm (RMS) V: 5mm±0.5ppm (RMS)
-Real-time Kinematic H: 8mm±1ppm (RMS) V: 15mm±1ppm (RMS)
-Battery Capacity 6800 mAh.
-Unit ringan dengan berat 740gram
-Penyimpanan 8gb SSD
-Waterproof & Dustproof IP68

Competible With Drone DJI
